ryandriftingfat · 03-06-2013, 11:08 AM

Nice to see everyone is painting their engine bays.

s13 drifta · 03-07-2013, 09:43 AM

Reroute that orange snake in front. It's out of place and takes away from the rest of the bay. Other than that, looks good.

shift_down · 03-09-2013, 05:30 PM

Quote:

Originally Posted by s13 drifta

Reroute that orange snake in front.

This cracked me up

These bays are awesome. The more I see them, the more changes I make to mine for the better.

heres my updated bay, still getting worked on:

ryandriftingfat · 03-07-2013, 02:41 PM

Already gone.

di-devol · 03-09-2013, 06:20 PM

Newtypex · 03-12-2013, 07:21 AM

tapdeznutz · 03-12-2013, 11:04 AM

looks like a metallic teal to me

Veryflush · 03-12-2013, 11:47 AM

My progression on my 400whp s13 coupe. All piping will be re done just did this piping setup to start it and make sure timing was correct.

Sent from my myTouch_4G_Slide using Tapatalk 2

shift_down · 03-12-2013, 12:21 PM

What is your piping wrapped in?

up in smoke · 03-12-2013, 12:23 PM

OutlawLui · 03-12-2013, 02:49 PM

Quote:

Originally Posted by up in smoke

aaaaaaaaaaaaaaaaaaaaaaaahahahahaaaahahaahahahah
troll

shift_down · 03-12-2013, 12:24 PM

lawl, fo real? you be trollin?

How doesnt it tear?

Sleepy_Steve · 03-12-2013, 01:04 PM

Quote:

Originally Posted by shift_down

lawl, fo real? you be trollin?

How doesnt it tear?

Possibly spray adhesive... At least the way it's wrinkled makes me think spray adhesive.

I foil-wrapped my BMC, lines, and o2 sensor wires when I stripped the threads out of the o2 bung and had to drive home from the track 4 hours with a half inch hole blowing hot gasses in the direction of my brakes. It was a gas station ghetto fix, but I got home without incident, and my BMC was too hot to touch when I stopped after the first 45 minutes.

Veryflush · 03-12-2013, 01:07 PM

Quote:

Originally Posted by shift_down

What is your piping wrapped in?

It's a cooling foil usually comes in gold. Very exspensive I have new inter cooing pipes. Glad that I now have a new buddy. I'm sure your not used to seeing ppl wrapping their pipes in heat reflective tape. It's exspensive so it's ok man, maybe one day you can afford it.

This was directed towards up in smoke since hes been following me around.

Sent from my myTouch_4G_Slide using Tapatalk 2

shift_down · 03-12-2013, 03:29 PM

Man you know what would be really cool, is painting the pipes with heat resistant paint. Its probably expensive though

Veryflush · 03-12-2013, 04:50 PM

Quote:

Originally Posted by shift_down

Man you know what would be really cool, is painting the pipes with heat resistant paint. Its probably expensive though

It isn't but the dude before me decided to wrap the piping in ugly gold heat reflective tape. I thought the aluminum reflective tape looked better for now. The shit is damn near impossible to remove. I'm going mid mount so all my piping will be re done.

Sent from my myTouch_4G_Slide using Tapatalk 2

BoostMunchies · 03-13-2013, 07:41 PM

My SR gettin ready to be resurrected...

Seraphim38 · 03-14-2013, 09:20 AM

finally done. Pic taken at the dyno shop while getting tuned.

turbo2nr · 03-14-2013, 07:29 PM

vmount/wiggins/gtx35r/build ka-t

check build threads for updates

milesbizzell · 03-14-2013, 07:55 PM

I cant figure out how to post a photo

om3ga · 03-14-2013, 08:20 PM

^^ Upload to Photobucket and copy the IMG Tags

Magical Trevor · 03-14-2013, 08:31 PM

Slowly but surely

SaNTi · 03-19-2013, 04:38 PM

Quote:

Originally Posted by Magical Trevor

Slowly but surely

This looks great. Nice and simple. Any more pics?

conrad_s13.5 · 03-15-2013, 02:54 PM

blackonblackonblack!

<3

BiG MiKE86 · 03-15-2013, 03:29 PM

Quote:

Originally Posted by Magical Trevor

Slowly but surely

That's a good looking bay

Magical Trevor · 03-16-2013, 10:37 PM

Quote:

Originally Posted by conrad_s13.5

blackonblackonblack!

<3

Quote:

Originally Posted by BiG MiKE86

That's a good looking bay

Thanks y'all. Lots of time, effort and money in the bay.

Dorifto Machine · 03-15-2013, 03:42 PM

Here is a shot of my setup, this is about 60% into the making of the swap. Updated images to come.

huffandpuff00 · 03-16-2013, 01:36 AM

back together w/ new tubs...

waxball88 · 03-16-2013, 12:18 PM

Ran with no filter, blow through is fun, need to repaint my bay

arlok · 03-16-2013, 05:57 PM

My old 95 Integra GSR

My S14
